1658691-1 by te connectivity / amp brand
DATA SHEET

1658691-1

TE Connectivity / AMP Brand

D Sub Connector Housing - 15 Positions - D Sub - 1 - AMPLIMITE HDP-22 Series - Plug - Steel Body. .. see full description

RoHS Compliant
Carton Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658691-1
RoHS:
Yes
HTS:
8538908180
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
400
Package Type:
Carton
Type:
High Density D-Sub
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
1
Number of Contacts:
15
Contact Plating:
N/A
Operating Temperature:
N/A
Using the high density d-sub 1658691-1 DVI connector from TE Connectivity is fast and easy for communicating between serial connections in your circuit. It has a straight body orientation. This 3-row connector has a single port. 1658691-1 is housed in nylon. Its 15 terminals use the crimp termination method. This product is 30.81 mm long, 12.55 mm tall and 18.21 mm deep.
Product Highlights:
  • Product Series = HDP-22 (Crimp Snap)
  • 15 Positions
  • Without Enclosure
  • Housing Gender = Plug
  • Without Contacts
Search Keywords:
16586911
IN STOCK: 4,921
Ships today, if you order in
MOQ for In Stock Qty:
5
MOQ for out of Stock Qty:
800
Factory Lead-Time
11 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$12.66
$63.300
250
$7.60
$1,900.000
500
$7.52
$3,760.000
800
$7.45
$5,960.000
1,600
$7.37
$11,792.000
2,400
$7.30
$17,520.000
3,200 +
$7.23
$23,136.000
Please Note: Item may be subject to tariff fee if shipping within the United States
