172334-1 by te connectivity / amp brand
DATA SHEET

172334-1

TE Connectivity / AMP Brand

MINI UMNL CAP HOUSING 15P .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
172334-1
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Bag
Mounting:
Panel Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
15
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
-20 to 105 °C
The TE Connectivity / AMP Brand part 172334-1 is a miniature Universal MATE-N-LOK (UMNL) cap housing, designed to provide a secure and reliable electrical connection. It features a 15-pin configuration, allowing for easy and efficient connectivity in various applications. This cap housing ensures protection for the electrical contacts and offers excellent resistance against environmental factors such as moisture and dust. With its compact size and durable construction, the 172334-1 is an ideal choice for applications requiring a reliable and space-efficient electrical connection solution.
Product Highlights:
  • Housing
  • Mini-Universal MATE-N-LOK
  • Number of Circuits = 15
  • 4.14 x 4.14 mm Centerline, Matrix
  • Matrix Contact Layout
Search Keywords:
1723341
IN STOCK: 7,298
Ships today, if you order in
Minimum Order:
25
Factory Lead-Time
16 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
25
$0.8097
$20.243
250
$0.6046
$151.150
500
$0.5980
$299.000
1,000
$0.5727
$572.700
2,500
$0.5620
$1,405.000
5,000
$0.5002
$2,501.000
7,500
$0.4952
$3,714.000
10,000 +
$0.4902
$4,902.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
