174147-2 by te connectivity / amp brand
DATA SHEET

174147-2

TE Connectivity / AMP Brand

070 MULTILOCK PLUG 16P .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
174147-2
RoHS:
Yes
HTS:
8538906000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Circuit Application:
Signal
Connector Position Assurance Capable:
No
Number of Rows:
2
Connector System:
Wire-to-Wire
Primary Locking Feature:
Integrated in Housing
Sealable:
No
Serviceable:
Yes
Primary Product Color:
Black
Operating Voltage:
12 VDC
Nominal Voltage Architecture:
12 V
Terminal Position Assurance:
Yes
Number of Positions:
16
Connector & Housing Type:
Housing for female terminals
UL Flammability Rating:
UL 94HB
Mating Alignment Type:
Polarized
Cable Exit Angle:
180°
Operating Temperature Range:
-30 – 105 °C, -22 – 221 °F
Centerline (Pitch):
.15 in, 3.8 mm
Row-to-Row Spacing:
.118 in, .138 in, 3 mm, 3.5 mm
Product Width:
1.248 in, 31.7 mm
Product Length:
.827 in, 21 mm
Operating Temperature (Max):
100 °C, 105 °C, 70 °C, 75 °C, 80 °C, 85 °C, 90 °C, 158 °F, 167 °F, 176 °F
Mating Tab Width:
.071 in, 1.8 mm
Contact Size:
1.8mm
Strain Relief:
Without
Housing Material:
PBT
Connector Shape:
Rectangular
Mating Alignment:
With
Connector Height:
1.039 in, 26.4 mm
Contact Type:
Receptacle
Connector Mounting Type:
Cable Mount (Free-Hanging)
070 MULTILOCK PLUG 16P
Product Highlights:
  • Housing
  • Plug
  • 040/070 Hybrid Plug Configuration
  • Number of Rows = 2
  • Number of Positions = 16
Search Keywords:
1741472
IN STOCK: 500
Ships today, if you order in
MOQ for In Stock Qty:
100
MOQ for out of Stock Qty:
300
Multiple:
100
Factory Lead-Time
18 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
100
$1.143
$114.300
300
$0.998
$299.400
600
$0.913
$547.800
900
$0.888
$799.200
1,200 +
$0.875
$1,050.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
