Supplier:
TE Connectivity / AMP Brand
Part No:
1-745496-8
RoHS:
Yes
HTS:
8536698000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack
84
Package Type:
Pack
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
IDT
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
25 HDE MS PLUG,22-26,LEAD FREE
Product Highlights:
- Connector
- Product Series = HDE-20 (IDC)
- Number of Positions = 25
- Plug
- With Contacts
Search Keywords:
17454968
IN STOCK:
707
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
10 Weeks
Quantity
Unit Price
Ext. Price
5
$9.16
$45.800
25
$8.36
$209.000
84
$7.86
$660.240
168
$7.79
$1,308.720
252
$7.71
$1,942.920
504
$7.63
$3,845.520
1,008
+
$7.55
$7,610.400
Please Note:
Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
3D PDF
Product Guides
Product Drawing - PLUG ASSY, METAL SHELL, SIZE 3, 25 POSN, SERIES HDE-20 FOR MASS TERMINATION
Datasheet
Product Specification - AMPLIMITE HDE-20 Insulation Displacement Connector
Instruction Sheet - AMPLIMITE High Den. (HDE-20) Insulation Displacement Metal Shell Conn.
