1757819-8 by te connectivity / amp brand
DATA SHEET

1757819-8

TE Connectivity / AMP Brand

25 Position D-Sub Plug, Male Pins Connector .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1757819-8
RoHS:
Yes
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
3
Number of Contacts:
25
Shell Plating Material:
Cadmium/Steel
Contact Plating:
N/A
Operating Temperature:
N/A
The 1757819-8 is a 25-position D-sub Plug Assembly with gold over nickel copper alloy contacts and zinc-plated steel shell. The Amplimite 109-series plug used with size-20 crimp snap-in contacts. Connector Style D-Sub Connector Type Plug, Male Pins Number of Positions 25 Number of Rows 2 Shell Size, Connector Layout 3 (DB, B) Contact Type Signal Mounting Type Free Hanging (In-Line) Flange Feature Housing/Shell (Unthreaded) Termination Crimp Applications Industrial
Product Highlights:
  • Connector
  • Product Series = 109
  • Density = Standard
  • Terminate To Wire
  • Number of Positions = 25
Search Keywords:
17578198
IN STOCK: 48
Ships today, if you order in
Factory Lead-Time
9 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1 +
$12.00
$12.000
