1757820-9 by te connectivity / amp brand
DATA SHEET

1757820-9

TE Connectivity / AMP Brand

D Sub Connector Housing - 37 Positions - D Sub - DC - AMPLIMITE 109 Series - Receptacle - Metal Body. .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1757820-9
RoHS:
Yes
HTS:
8536694030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
SKT
Termination Method:
Crimp
Shell Size:
4
Number of Contacts:
37
Shell Plating Material:
Zinc/Steel
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 125 °C
The 1757820-9 is a 37-way black D-sub Receptacle Assembly with gold-plated copper alloy crimp snap-in contacts. It comes with a zinc-plated steel shell, mounting holes and stainless steel retention clip.
Product Highlights:
  • Connector
  • Product Series = 109
  • Density = Standard
  • Terminate To Wire
  • Number of Positions = 37
Search Keywords:
17578209
IN STOCK: 302
Can Ship immediately
On Order:
268   can ship 11/28/24
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$23.90
$23.900
50
$23.30
$1,165.000
100
$20.70
$2,070.000
250 +
$19.70
$4,925.000
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
