1-770178-1 by te connectivity / amp brand
DATA SHEET

1-770178-1

TE Connectivity / AMP Brand

Connector Header Through Hole 6 position 0.163" (4.14mm) .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-770178-1
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Bag
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
6
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A
The 1-770178-1 is a Wire-To-Board Connector, 4.14 mm, 6 Contacts, Plug, Mini Universal MATE-N-LOK Series, Through Hole. Contact Type Male Pin Pitch - Mating 0.163" (4.14mm) Number of Positions 6 Number of Rows 2 Row Spacing - Mating 0.163" (4.14mm) Number of Positions Loaded All Style Board to Cable/Wire Shrouding Shrouded - 4 Wall Mounting Type Through Hole Termination Solder Fastening Type Locking Ramp Contact Length - Post 0.175" (4.45mm) Insulation Height 0.531" (13.50mm) Contact Shape Circular Contact Finish - Mating Gold Contact Finish Thickness - Mating 30.0µin (0.76µm) Contact Finish - Post Tin Contact Material Brass Insulation Material Polyamide (PA), Nylon Features Board Lock Operating Temperature -20°C ~ 105°C
Product Highlights:
  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 6
  • 4.14 x 4.14 mm Centerline, Matrix
  • Double-Row Contact Layout
Search Keywords:
17701781
IN STOCK: 7,001
Can Ship immediately
Minimum Order:
10
Factory Lead-Time
4 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$1.775
$17.750
200
$1.436
$287.200
400
$1.415
$566.000
600
$1.381
$828.600
1,000
$1.346
$1,346.000
2,600
$1.333
$3,465.800
5,000
$1.307
$6,535.000
7,600 +
$1.294
$9,834.400
Suppliers Standard Package
