1-770858-0
TE Connectivity / AMP BrandWire-To-Board Connector - 4.14 mm - 10 Contacts - Header - Mini Universal MATE-N-LOK Series. .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-770858-0
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack
200
Package Type:
Bag
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
10
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A
The 1-770858-0 power connector from TE Connectivity for a secure connection! This HDR connector's 10 contacts that are made out of brass and plated with tin over nickel. This connector has a single port. Its pitch is 4.14 mm. It has a maximum voltage rating of 600 VAC. It has a straight body orientation. It has a header type gender. 1-770858-0 is housed in nylon. This device has a maximum current rating of 9.5 A/contact. This product is 14.25 mm tall. Its 10 terminals use the solder termination method.
Search Keywords:
17708580
IN STOCK:
7,489
Ships today, if you order in
Manufacturer Stock:
17,200
can ship
12/2/24
Minimum Order:
10
Factory Lead-Time
4 Weeks
can ship
12/13/24
Quantity
Unit Price
Ext. Price
10
$2.06
$20.600
200
$1.52
$304.000
400
$1.50
$600.000
600
$1.47
$882.000
1,000
$1.45
$1,450.000
2,600
$1.43
$3,718.000
5,000
$1.41
$7,050.000
7,600
+
$1.39
$10,564.000
Tools/3D Models
3D PDF
Product Guides
Product Drawing - HDR ASSY, CLOSED BOTTOM 10 CRT DBLE ROW VERTICAL MINI UNIVERSAL MATE-N-LOK
Datasheet
Material Declaration - MD_1-770858-0_04262017811_dmtec
Instruction Sheet - Instruction Sheet - Mini-Universal MATE-N-LOK Connectors
Product Changes
