1-770872-0 by te connectivity / amp brand
DATA SHEET

1-770872-0

TE Connectivity / AMP Brand

Wire-To-Board Connector - 4.14 mm - 2 Contacts - Plug - Mini Universal MATE-N-LOK Series - Through Hole. .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-770872-0
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Bag
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
2
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A
The 1-770872-0 power connector from TE Connectivity is perfect for powering your circuit because it comes with the least amount of losses. This HDR connector's 2 contacts that are made out of brass and plated with tin over nickel. This connector has a single port. It has a straight body orientation. Its pitch is 4.14 mm. It has a header type gender. It has a maximum voltage rating of 600 VAC. 1-770872-0 is housed in nylon. This device has a maximum current rating of 9.5 A/contact. This product is 13.69 mm long, 14.25 mm tall and 6.35 mm deep. Its 2 terminals use the solder termination method.
Product Highlights:
  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 2
  • 4.14 mm Centerline, Matrix
  • In-Line Contact Layout
Search Keywords:
17708720
IN STOCK: 13,004
Can Ship immediately
Minimum Order:
200
Multiple:
200
Factory Lead-Time
12 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
200
$0.644
$128.800
400
$0.635
$254.000
600
$0.625
$375.000
1,000
$0.616
$616.000
2,600
$0.606
$1,575.600
5,000
$0.597
$2,985.000
7,600
$0.588
$4,468.800
10,000 +
$0.580
$5,800.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
