1-770968-1 by te connectivity / amp brand
DATA SHEET

1-770968-1

TE Connectivity / AMP Brand

Rectangular Power Connector - Header - Male Pin - 4 Position - 2 Rows - 0.163"(4.14mm) Pitch - 600VAC - Solder Termination -Through Hole, Right Angle. .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-770968-1
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Bag
Type:
Power
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
4
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A
The 1-770968-1 is rectangular power connector with locking ramp and board lock. Operating temperature range is from -20°C to 105°C.
Product Highlights:
  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 4
  • 4.14 x 4.14 mm Centerline, Matrix
  • Double-Row Contact Layout
Search Keywords:
17709681
IN STOCK: 16,294
Can Ship immediately
Manufacturer Stock:
3,400   can ship 12/6/24
Minimum Order:
5
Factory Lead-Time
4 Weeks can ship 12/19/24
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$3.63
$18.150
50
$2.48
$124.000
200
$2.34
$468.000
400
$2.31
$924.000
600
$2.27
$1,362.000
1,000
$2.24
$2,240.000
2,600
$2.21
$5,746.000
5,000 +
$2.17
$10,850.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
