1-770974-1 by te connectivity / amp brand
DATA SHEET

1-770974-1

TE Connectivity / AMP Brand

16P MINI UMNL R/A HDR ASSY LF .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-770974-1
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Bag
Type:
Power
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
16
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A
The TE Connectivity / AMP Brand part 1-770974-1 is a 16-pin, right-angle header assembly designed for use in miniature universal mate n' lock connectors. This assembly offers a low-profile design and is lead-free, making it suitable for environmentally conscious applications. With its compact size and efficient design, it provides a reliable and secure connection for your electronic projects.
Product Highlights:
  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 16
  • 4.14 x 4.14 mm Centerline, Matrix
  • Double-Row Contact Layout
Search Keywords:
17709741
IN STOCK: 340
Ships today, if you order in
Minimum Order:
5
Factory Lead-Time
12 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$10.63
$53.150
25
$10.47
$261.750
50
$9.52
$476.000
200
$9.42
$1,884.000
400
$9.33
$3,732.000
600
$9.24
$5,544.000
1,000 +
$9.14
$9,140.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
