1-776087-2 by te connectivity / amp brand
DATA SHEET

1-776087-2

TE Connectivity / AMP Brand

23POS,PIN DIA 1.3,HDR ASSY,90DEG,COD 2 .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-776087-2
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Package Type:
Tray
Type:
Power
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
23
Termination Method:
Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
17/Contact A
Operating Temperature:
-40 to 125 °C
The Part 1-776087-2 is a Header Assembly specifically designed for the AMP brand's AMPSEAL connectors. With 23 positions, this right-angle header assembly offers a convenient and efficient solution for connecting wires in various applications. It is built with high-quality materials, ensuring reliable and secure connections. This header assembly is an essential component for achieving a dependable electrical connection in automotive, industrial, and commercial settings.
Product Highlights:
  • Header Assembly
  • Number of Positions = 23
  • Terminate To Panel, Terminate To Printed Circuit Board
  • Right Angle Mount Angle
  • With Gasket
Search Keywords:
17760872
IN STOCK: 500
Ships today, if you order in
MOQ for In Stock Qty:
5
MOQ for out of Stock Qty:
50
Factory Lead-Time
13 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$22.86
$114.300
10
$17.70
$177.000
25
$15.33
$383.250
50
$13.93
$696.500
100
$13.50
$1,350.000
150
$13.08
$1,962.000
200 +
$12.95
$2,590.000
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
