1-776228-4 by te connectivity / amp brand
DATA SHEET

1-776228-4

TE Connectivity / AMP Brand

23POS,PIN DIA 1.3,HDR ASSY,180DEG,COD 4 .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-776228-4
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Package Type:
Tray
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
23
Termination Method:
Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
17/Contact A
Operating Temperature:
-40 to 125 °C
Our TE Connectivity / AMP Brand part 1-776228-4 is a high-quality 23-position header assembly with a compact design. This connector features a pin diameter of 1.3mm and is designed for 180-degree configurations, with coding to ensure proper alignment during installation. Built with precision and durability in mind, this header assembly is ideal for various electronic applications requiring reliable connectivity.
Product Highlights:
  • Header Assembly
  • Number of Positions = 23
  • Terminate To Panel, Terminate To Printed Circuit Board
  • Vertical Mount Angle
  • With Gasket
Search Keywords:
17762284
IN STOCK: 796
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
13 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$12.92
$64.600
40
$9.23
$369.200
80
$9.13
$730.400
120
$9.04
$1,084.800
280
$8.95
$2,506.000
520
$8.86
$4,607.200
1,000 +
$8.77
$8,770.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
