DATA SHEET

205840-3

TE Connectivity / AMP Brand

28 Position Circular Connector Receptacle Housing Panel Mount .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
205840-3
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Type:
CPC
Gender:
RCP
Body Orientation:
Straight
Mounting:
Panel Mount
Shell Size / Insert Arrangement:
17-28
Number of Contacts:
28
Contact Gender:
Pin
Contact Plating:
N/A
Termination Method:
Crimp
Maximum Current Rating:
N/A
Maximum Voltage Rating:
N/A
TE Connectivity Series 2 High-Density CPC Connectors are designed to accept Size 20 DF (precision formed) and Size 20 (DM screw-machined) pin and socket contacts with a .040 [1.02] pin diameter. The Size 20 DF contacts are available in crimp and solder versions, as well as a posted version for wrap-type and PC board applications. Series 2 High-Density CPCs provide a maximum current carrying capability of 7.5 amperes and many connector arrangements. These connector arrangements offer both standard and reverse sex contact loading—from 8 thru 63 positions. Number of Positions 28 Shell Size - Insert 17-28 Contact Type Crimp Contact Size 20 Shell Material Thermoplastic Housing Color Black Material Flammability Rating UL94 V-0 Shielding Unshielded Note Contacts Not Included Insert Material Thermoplastic Contact Shape Circular Operating Temperature -55°C ~ 105°C
Product Highlights:
  • Without Contacts
  • 28 Positions
  • 28 Signal Positions
  • 0 Power Positions
  • Housing Gender = Receptacle
Search Keywords:
2058403
IN STOCK: 697
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$8.32
$41.600
25
$6.23
$155.750
50
$6.12
$306.000
100
$6.02
$602.000
300
$5.93
$1,779.000
500
$5.84
$2,920.000
1,000 +
$5.75
$5,750.000
