206039-1 by te connectivity / amp brand
DATA SHEET

206039-1

TE Connectivity / AMP Brand

28 Position Circular Connector Plug Housing Free Hanging (In-Line) Coupling Nut .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
206039-1
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Type:
CPC
Gender:
PL
Body Orientation:
Straight
Mounting:
Cable Mount
Shell Size / Insert Arrangement:
17-28
Number of Contacts:
28
Contact Gender:
Pin
Contact Plating:
N/A
Termination Method:
Crimp
Maximum Current Rating:
N/A
Maximum Voltage Rating:
N/A
The 206039-1 is a 28-position Free Hanging Plug with socket type contacts and 17-28 insert arrangement. The reverse sex circular plastic connector is made of UL94V-0 rated black thermoplastic. The series 2 connector accepts size 20 DF (precision formed) and size 20 DM (screw-machined) pin contacts. Maximum current carrying capability is 7.5A. Lightweight Quick connect/disconnect capability with thread assist, positive detent coupling Polarized for proper mating of connector halves Keyed mating alignment Threaded coupling mating retention Contact protection Applications Commercial, Signal Processing, Power Management
Product Highlights:
  • Connector
  • Number of Positions = 28
  • Plug
  • For Use With Pin Contacts
  • Not Preloaded
Search Keywords:
2060391
IN STOCK: 3,735
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
13 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$8.86
$44.300
25
$6.33
$158.250
50
$6.21
$310.500
100
$6.11
$611.000
300
$6.02
$1,806.000
500
$5.93
$2,965.000
1,000 +
$5.84
$5,840.000
