DATA SHEET

2-111196-5

TE Connectivity / AMP Brand

Wire-To-Board Connector - 1.27 mm - 10 Contacts - Receptacle - AMPMODU System 50 Series - IDC / IDT. .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-111196-5
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
110
Package Type:
Tray
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
RCP
Mounting:
Cable Mount
Pitch:
1.27 mm
Number of Contacts:
10
Maximum Voltage Rating:
30 VAC
Maximum Current Rating:
0.5/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C
The 1445692-4 is AMPMODU System 50 series Connector includes a wide variety of high density board-to-board (thru-hole and surface-mount) and cable-to-board connectors. The AMPMODU System 50 is composed of one and two-row receptacles and post headers on 0.050x0.100-inch (1.27x2.54mm) spacing between contacts for extreme density and efficient use of printed circuit board area. AMPMODU System 50 receptacles and header assemblies can be categorized in three groups, board-mount headers, board-mount receptacles and cable-to-board receptacles. Receptacle contacts and mating 0.0150inch (0.38mm) square posts are formed from high conductivity copper alloy and are selectively plated with gold to promote higher performance and reliability. Board-mounted thru-hole post headers and receptacle connectors are available for right-angle and vertical mating configurations. Surface-mounted connectors are available in vertical, double row styles for parallel stacking applications.
Product Highlights:
  • Receptacle Assembly
  • Number of Positions = 10
  • Number of Rows = Dual
  • With Mating Connector Lock
  • Wire/Cable Type = Ribbon Cable
Search Keywords:
21111965
IN STOCK: 1,475
Ships today, if you order in
MOQ for In Stock Qty:
5
MOQ for out of Stock Qty:
413
Factory Lead-Time
7 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$5.552
$27.760
100
$4.533
$453.300
250
$4.376
$1,094.000
413
$4.332
$1,789.116
825
$4.288
$3,537.600
1,238
$4.246
$5,256.548
1,650 +
$4.203
$6,934.950
Please Note: Item may be subject to tariff fee if shipping within the United States
