2-1761603-7 by te connectivity / amp brand
DATA SHEET

2-1761603-7

TE Connectivity / AMP Brand

Wire-To-Board Connector - 2.54 mm - 20 Contacts - Header - AMP-LATCH Series - Through Hole - 2 Rows. .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-1761603-7
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Package Type:
Tray
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
20
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Termination Method:
Solder
Operating Temperature:
N/A
The 2-1761603-7 is a 20-way 2-row Connector Header with PBT housing and gold-plated phosphor bronze contacts, 2.54mm pitch spacing and through hole termination. This connector header is suitable for use with printed circuit board.
Product Highlights:
  • Connector Type = Pin Header
  • Low Profile
  • Number of Positions = 20
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Vertical
Search Keywords:
217616037
IN STOCK: 1,550
Ships today, if you order in
MOQ for In Stock Qty:
5
MOQ for out of Stock Qty:
800
Factory Lead-Time
13 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$4.47
$22.350
250
$3.11
$777.500
500
$3.07
$1,535.000
800
$3.02
$2,416.000
1,600
$2.97
$4,752.000
2,400
$2.93
$7,032.000
3,200 +
$2.89
$9,248.000
Please Note: Item may be subject to tariff fee if shipping within the United States
Older Equivalent
2-827745-0
2-827745-0
VIEW PRODUCT
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
