2-5747707-0
TE Connectivity / Amp BrandD Sub Connector - DB15 - 15 Contacts - Receptacle - Through Hole - AMPLIMITE HD-20 Series. .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
2-5747707-0
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
2
Number of Contacts:
15
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
The 2-5747707-0 is a 15-way 2-row front metal shell D-sub Plug with gold-plated brass contacts and clear chromate-plated zinc 4-40 UNC threaded inserts. The Amplimite HD-20 series right angle posted plug comes with grounding indents, grounding straps, black nylon/polyester housing, tin-plated brass eyelet, tin-plated carbon steel shell and tin-plated solder tail.
Product Highlights:
- 15 Positions
- Receptacle
- PCB Mount Angle = Vertical
- Product Series = HD 20
- Without Mating Connector Lock
Search Keywords:
257477070
IN STOCK:
32
Can Ship immediately
Minimum Order:
13
Multiple:
13
Factory Lead-Time
6 Weeks
Quantity
Unit Price
Ext. Price
13
$4.057
$52.741
52
$2.592
$134.784
104
$2.505
$260.520
260
$2.405
$625.300
507
$2.342
$1,187.394
1,001
$2.330
$2,332.330
2,509
$2.318
$5,815.862
5,005
+
$2.307
$11,546.535
