2-5748003-0 by te connectivity / amp brand
DATA SHEET

2-5748003-0

TE Connectivity / AMP Brand

09 PLUG SP/FMS BRDLK .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-5748003-0
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
The TE Connectivity / AMP Brand part 2-5748003-0 is a 09 pin plug with a SP/FMS BRDLK design. This high-quality connector is designed to securely lock onto the corresponding receptacle, ensuring a reliable and secure connection for your electrical circuits. Its compact size and durable construction make it suitable for a wide range of applications in industries such as automotive, telecommunications, and industrial equipment. Trust TE Connectivity / AMP Brand for top-notch electrical components.
Product Highlights:
  • Number of Positions = 9
  • Plug
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • Without Mating Connector Lock
Search Keywords:
257480030
IN STOCK: 2,634
Ships today, if you order in
Minimum Order:
17
Multiple:
17
Factory Lead-Time
2 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
17
$4.283
$72.811
51
$3.899
$198.849
102
$3.759
$383.418
255
$3.636
$927.180
510
$3.600
$1,836.000
1,003
$3.564
$3,574.692
2,516
$3.528
$8,876.448
5,015 +
$3.493
$17,517.395
