2-647125-4 by te connectivity / amp brand
DATA SHEET

2-647125-4

TE Connectivity / AMP Brand

04P MTA156 SHRD HDR ASSY LF .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-647125-4
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Bag
Mating Retention Type:
Latch Detent
Number of Positions:
4
Contact Retention Within Housing:
Without
Circuit Application:
Power
Housing Material:
Polyester - GF
Packaging Quantity:
500
Right Angle Bending Side:
Front
Connector & Contact Terminates To:
Printed Circuit Board
Connector Mounting Type:
Board Mount
Termination Method to Printed Circuit Board:
Through Hole - Solder
Glow Wire Rating:
Standard Part - Not Glow Wire
Mating Retention:
With
Number of Rows:
1
PCB Mount Orientation:
Right Angle
Contact Mating Area Plating Material:
Tin
Rectangular Power Connector Type:
Header
Panel Mount Feature:
Without
Number of Power Positions:
4
Contact Mating Area Plating Material Finish:
Matte
Mating Alignment:
With
Contact Base Material:
Copper Alloy
PCB Mount Alignment:
Without
UL Flammability Rating:
UL 94V-0
PCB Mount Retention:
Without
Sealable:
No
Connector Profile:
Standard
Contact Current Rating (Max):
7 A
Strain Relief:
Without
Mating Alignment Type:
Polarization
Connector & Housing Type:
Plug
Contact Underplating Material:
Nickel
Contact Layout:
Inline
PCB Contact Termination Area Plating Material:
Tin
Connector System:
Wire-to-Board
UL Rating:
Recognized
Housing Color:
Black
Operating Voltage:
600 VAC
Contact Type:
Pin
Header Type:
Fully Shrouded
Agency/Standard:
CSA , UL
Contact Mating Area Plating Material Thickness:
3.81 – 8.89 µin, 150 – 350 µm
Centerline (Pitch):
.156 in, 3.96 mm
PCB Thickness (Recommended):
.062 in, 1.57 mm
Termination Post & Tail Length:
.118 in, 3 mm
Operating Temperature Range:
-55 – 105 °C, -67 – 221 °F
Mating Post Length:
.3 in, 7.62 mm
Packaging Method:
Box & Carton
Connector Height:
.525 in, 13.34 mm
CSA Rating:
Certified , LR 7189
Product Length:
.718 in, 18.24 mm
PCB Contact Termination Area Plating Material Thickness:
39.37 µin, 1 µm
Approved Standards:
UL E28476
Contact Underplating Material Thickness:
50 µin, 1.27 µm
The TE Connectivity / AMP Brand part 2-647125-4 is a 04P MTA156 SHRD HDR ASSY LF. This assembly features a compact 04-pin header with a MTA156 connector designed for secure and reliable connections. The header is fully shielded for improved protection against interference and features a low profile for space-constrained applications. This assembly is lead-free, making it an environmentally friendly choice. Ideal for a variety of electronic applications, this assembly offers a high level of performance and durability.
Search Keywords:
26471254
IN STOCK: 7
Can Ship immediately
You may purchase in-stock quantity up to 7
MOQ for In Stock Qty:
10
Available in less than min:
7
MOQ for out of Stock Qty:
750
Factory Lead-Time
17 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$3.993
$3.993
10
$3.630
$36.300
250
$2.340
$585.000
500
$2.270
$1,135.000
750
$2.200
$1,650.000
1,500
$2.170
$3,255.000
2,250
$2.140
$4,815.000
3,000 +
$2.100
$6,300.000
