282189-7 by te connectivity / amp brand
DATA SHEET

282189-7

TE Connectivity / AMP Brand

SPLASH PROOF CONN. W.S.L. .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
282189-7
RoHS:
Yes
HTS:
8538906000
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
600
Package Type:
Bag
Connector System:
Wire-to-Wire
Serviceable:
No
Operating Voltage:
24 VDC
Number of Rows:
1
Terminal Position Assurance:
Yes
Sealable:
Yes
Connector & Housing Type:
Housing for female terminals
Number of Positions:
2
Primary Product Color:
Yellow
Packaging Method:
Bag
Primary Locking Feature:
On the Terminal
Connector Position Assurance Capable:
No
Cable Exit Angle:
180°
Operating Temperature (Max):
100 °C, 105 °C, 110 °C, 120 °C, 125 °C, 70 °C, 75 °C, 80 °C, 85 °C, 90 °C
Product Width:
.866 in, 22 mm
Mating Tab Width:
.118 in, 3 mm
Operating Temperature Range:
-30 – 125 °C, -22 – 257 °F
Mating Alignment:
With
Strain Relief:
Without
Housing Material:
PA
Connector Mounting Type:
Cable Mount (Free-Hanging)
Connector Shape:
Rectangular
Nominal Voltage Architecture:
24 V
Product Length:
1.476 in, 37.5 mm
Contact Current Rating (Max):
20 A
Contact Type:
Receptacle
Centerline (Pitch):
.196 in, 5 mm
Contact Size:
2.8mm
Connector Height:
.937 in, 23.8 mm
Circuit Application:
Power
Connector & Contact Terminates To:
Wire & Cable
Mating Alignment Type:
Polarization Slot
TE Connectivity / AMP Brand part 282189-7 is a high-quality, reliable splash-proof connector that is available for purchase. This connector is designed to withstand moisture and splashes, making it suitable for use in a variety of applications including outdoor and damp environments. It provides a secure connection, ensuring reliable performance even in challenging conditions. The connector is versatile, with a wide range of uses and compatibility with various electronic devices. Trustworthy and durable, this product offers the peace of mind you need for your electrical connections. Please note that availability may be limited.
Product Highlights:
  • Housing Assembly
  • Connector Type = Junior Power Timer
  • Number of Positions = 2
  • PA 6.6 Housing Material
  • Housing Color = Yellow
Search Keywords:
2821897
IN STOCK: 11,636
Can Ship immediately
MOQ for In Stock Qty:
25
MOQ for out of Stock Qty:
2100
Factory Lead-Time
9 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
25
$1.074
$26.850
500
$0.943
$471.500
1,000
$0.929
$929.000
2,100
$0.915
$1,921.500
4,200
$0.906
$3,805.200
6,300
$0.897
$5,651.100
8,400 +
$0.888
$7,459.200
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
