3-1827233-6 by te connectivity / amp brand
DATA SHEET

3-1827233-6

TE Connectivity / AMP Brand

Stacking Board Connector - Free Height - FSI Series - 440 Contacts - Plug - 0.5 mm - Surface Mount. .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-1827233-6
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
18
Package Type:
Tray
Type:
Fine Pitch Connector
Body Orientation:
Straight
Gender:
PL
Mounting:
Surface Mount
Pitch:
0.5 mm
Number of Contacts:
440
Maximum Voltage Rating:
50 VAC
Maximum Current Rating:
0.5/Contact A
Termination Method:
Solder
Operating Temperature:
-40 to 85 °C
The 3-1827233-6 is a 440-way 4-row 0.5mm Free Height Vertical Plug with gold-plated copper alloy contacts and surface mount termination. This FH series connector comes with black high temperature thermoplastic housing and tin-plated solder tail, designed for parallel board to board stacking applications that require high density. The 0.5mm FH product is specified by the PICMG COM Express standard as the module to carrier card interface.
Product Highlights:
  • Plug
  • Family Name = Free Height
  • .50 mm Centerline
  • Number of Positions = 440
  • In-Line Contact Layout
Search Keywords:
318272336
IN STOCK: 670
Ships today, if you order in
MOQ for out of Stock Qty:
162
Factory Lead-Time
2 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$49.75
$49.750
50
$38.33
$1,916.500
100
$37.75
$3,775.000
162
$37.19
$6,024.780
324
$36.63
$11,868.120
486
$36.08
$17,534.880
648 +
$35.54
$23,029.920
Please Note: Item may be subject to tariff fee if shipping within the United States
