3-1827253-6 by te connectivity / amp brand
DATA SHEET

3-1827253-6

TE Connectivity / AMP Brand

The 0.5mm Free Height (FH) Connector from TE is part of a two-part connector system designed for parallel board-to-board stacking applications. Primarily reserved for applications that require high density the FH connector is used heavily in telecom and industrial applications. Featuring 220 positions and a Giga Ground Shield the connectors are, like all TE parts, RoHS compliant. .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-1827253-6
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
Tray
Type:
Fine Pitch Connector
Body Orientation:
Straight
Gender:
PL
Mounting:
Surface Mount
Pitch:
0.5 mm
Number of Contacts:
220
Maximum Voltage Rating:
50 VAC
Maximum Current Rating:
0.5/Contact A
Termination Method:
Solder
Operating Temperature:
-40 to 85 °C
The 0.5mm Free Height (FH) Connector from TE is part of a two-part connector system designed for parallel board-to-board stacking applications. Primarily reserved for applications that require high density the FH connector is used heavily in telecom and industrial applications. Featuring 220 positions and a Giga Ground Shield the connectors are, like all TE parts, RoHS compliant.
Product Highlights:
  • Plug
  • Family Name = Free Height
  • .50 mm Centerline
  • Number of Positions = 220
  • In-Line Contact Layout
Search Keywords:
318272536
IN STOCK: 666
Can Ship immediately
On Order:
660   can ship 12/23/24
Factory Lead-Time
2 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$20.62
$20.620
10
$18.55
$185.500
30
$17.62
$528.600
60
$16.74
$1,004.400
120
$15.91
$1,909.200
270
$15.59
$4,209.300
510 +
$15.12
$7,711.200
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
