Supplier:
TE Connectivity / AMP Brand
Part No:
320560
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack
1000
Package Type:
Box
Type:
PIDG Ring Tongue Terminal
Gender:
N/A
Tab Size:
N/A
Stud Size:
4 mm
Wire Size:
14-16 AWG
Color:
Blue
Operating Temperature:
105(Max) °C
The TE Connectivity / AMP Brand part 320560 is a high-quality PIDG R 16-14 8 terminal. This terminal is specifically designed for use in electrical connections where reliability and performance are crucial. With its durable construction and secure crimping capabilities, this terminal ensures a secure and long-lasting connection. It is suitable for various applications and is compatible with wires ranging from 16 to 14 gauge. Trust the TE Connectivity / AMP Brand 320560 terminal for your electrical needs.
Product Highlights:
- Terminal Shape = Ring Tongue
- Receptacle Style = Straight
- Body Style = PIDG
- Barrel Type = Closed Barrel
- Wire/Cable Type = Regular Wire
Search Keywords:
320560
IN STOCK:
116,148
Can Ship immediately
On Order:
50,000
can ship 6/11/25
Minimum Order:
1000
Multiple:
1000
Factory Lead-Time
30 Weeks
Quantity
Unit Price
Ext. Price
1,000
$0.1853
$185.300
3,000
$0.1781
$534.300
5,000
$0.1754
$877.000
8,000
$0.1728
$1,382.400
10,000
$0.1668
$1,668.000
25,000
$0.1643
$4,107.500
50,000
$0.1618
$8,090.000
100,000
+
$0.1594
$15,940.000
3D PDF
Product Guides
Product Drawing - TERMINAL, RING TONGUE, P.I.D.G. WIRE SIZE: 16-14 AWG
Datasheet
Agency Approval Document - WIRE CONN, TERMINALS, BUTT AND PARALLEL CONNECTORS-PLASTI-GRIP, SOLISTRAND, STD B, DIAMOND GRIP, PIDG AND AMPOWER REPORT
Product Changes
