3-520140-2 by te connectivity / amp brand
DATA SHEET

3-520140-2

TE Connectivity / AMP Brand

Quick Disconnect Terminal - Ultra-Fast FASTON Series - Female Quick Disconnect - 6.35mm x 0.81mm. .. see full description

RoHS Compliant
Reel Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-520140-2
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
Reel
Type:
Quick Disconnect Terminal
Gender:
F
Tab Size:
5.14 mm²
Stud Size:
N/A
Wire Size:
14-16 AWG
Color:
Blue Translucent
Operating Temperature:
105(Max) °C
The 3-520140-2 is Ultra-Fast FASTON series ultra-fast fully insulated FASTON Receptacle offers the advantage of a completely protected terminal and a wire crimp with comparable electromechanical performance to open barrel F crimp FASTON terminals. The user-friendly design combines easy mating with rounded corners. The ultra-fast FASTON receptacle housing completely encloses a tin plated copper alloy premier FASTON receptacle which has been stress-relieved for increased durability and resistance to abuse.
Product Highlights:
  • Receptacle
  • Proprietary Name = Ultra-Fast
  • Receptacle Style = Straight
  • Tab Fit = 6.35 x 0.81 mm
  • Brass Material
Search Keywords:
35201402
  Different packaging options available.  See Alternatives
IN STOCK: 442,000
Can Ship immediately
Minimum Order:
2000
Multiple:
2000
Factory Lead-Time
4 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
2,000
$0.1226
$245.200
4,000
$0.1172
$468.800
6,000
$0.1155
$693.000
8,000
$0.1137
$909.600
26,000
$0.1108
$2,880.800
50,000
$0.1064
$5,320.000
100,000
$0.1048
$10,480.000
150,000 +
$0.1033
$15,495.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
