3-640428-5 by te connectivity / amp brand
DATA SHEET

3-640428-5

TE Connectivity / AMP Brand

05P MTA156 CONN ASSY 22AWG RED .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-640428-5
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
Bag
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
3.96 mm
Number of Contacts:
5
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
7/Contact A
Termination Method:
IDT
Operating Temperature:
-55 to 105 °C
The TE Connectivity / AMP Brand part 3-640428-5 is a 05P MTA156 connector assembly with 22 AWG red wires. This connector provides a reliable and secure connection for your electrical applications. It features a compact design and easy installation, making it suitable for various industrial and automotive projects. The 22 AWG red wires are color-coded for easy identification and ensure efficient power transmission. With its high-quality construction and dependable performance, this connector assembly is an ideal choice for your wiring needs.
Product Highlights:
  • Connector
  • 5 Positions
  • Connector Type = Receptacle
  • Connector Style = Closed End
  • MTA-156 Product Line
Search Keywords:
36404285
IN STOCK: 20,049
Ships today, if you order in
Manufacturer Stock:
22,750   can ship 12/6/24
Minimum Order:
250
Multiple:
250
Factory Lead-Time
12 Weeks can ship 2/13/25
Enter Quantity
Quantity
Unit Price
Ext. Price
250
$0.2890
$72.250
1,000
$0.2819
$281.900
2,500
$0.2748
$687.000
5,000
$0.2634
$1,317.000
7,500
$0.2594
$1,945.500
10,000
$0.2556
$2,556.000
15,000
$0.2517
$3,775.500
25,000 +
$0.2479
$6,197.500
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
