3-643817-9 by te connectivity / amp brand
DATA SHEET

3-643817-9

TE Connectivity / AMP Brand

09P MTA156 CONN ASSY 18AWG LF .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-643817-9
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
Bag
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
3.96 mm
Number of Contacts:
9
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
7/Contact A
Termination Method:
IDT
Operating Temperature:
-55 to 105 °C
The TE Connectivity/AMP Brand part 3-643817-9 is a 09P MTA156 Connector Assembly. It features 18AWG wire size and is made with lead-free materials. This connector assembly provides a reliable and secure connection for a variety of applications.
Product Highlights:
  • MTA-156 Connectors
  • Number of Positions = 9
  • Mating Type = Receptacle
  • Connector Type = Closed End
  • Wire-to-Board Application
Search Keywords:
36438179
IN STOCK: 5,500
Ships today, if you order in
On Order:
9,000   can ship 7/28/25
Minimum Order:
250
Multiple:
250
Factory Lead-Time
45 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
250
$0.6826
$170.650
500
$0.6246
$312.300
1,000
$0.5853
$585.300
2,500
$0.5054
$1,263.500
5,000
$0.5003
$2,501.500
7,500
$0.4953
$3,714.750
10,000
$0.4904
$4,904.000
15,000 +
$0.4855
$7,282.500
