3-644759-5 by te connectivity / amp brand
DATA SHEET

3-644759-5

TE Connectivity / AMP Brand

05P MTA156 HDR ASSY STR LF

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-644759-5
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
Pack
Contact Retention Within Housing:
Without
Packaging Method:
Package
Mating Retention Type:
Friction Lock
Termination Method to Printed Circuit Board:
Through Hole - Solder
Contact Base Material:
Copper Alloy
PCB Mount Orientation:
Vertical
Connector & Contact Terminates To:
Printed Circuit Board
Number of Positions:
5
Rectangular Power Connector Type:
Header
Strain Relief:
Without
UL Flammability Rating:
UL 94V-0
Connector System:
Wire-to-Board
Operating Voltage:
600 VAC
Housing Material:
Thermoplastic Polyester - GF
PCB Mount Alignment:
Without
Housing Color:
Natural
Connector & Housing Type:
Receptacle
Sealable:
No
Glow Wire Rating:
Standard Part - Not Glow Wire
Contact Layout:
Inline
Panel Mount Feature:
Without
PCB Contact Termination Area Plating Material:
Tin
Circuit Application:
Power
Contact Current Rating (Max):
7 A
Connector Mounting Type:
Board Mount
Mating Retention:
With
Packaging Quantity:
2000
Mating Alignment:
Without
UL Rating:
Recognized
PCB Mount Retention:
Without
Contact Underplating Material:
Nickel
Number of Signal Positions:
0
Number of Power Positions:
5
Number of Rows:
1
Header Type:
Partially Shrouded
Contact Type:
Pin
Mating Post Length:
.4 in, 10.16 mm
Agency/Standard:
CSA , UL
Contact Mating Area Plating Material Thickness:
30 µin, .76 µm
Operating Temperature Range:
-55 – 105 °C, -67 – 221 °F
Termination Post & Tail Length:
.125 in, 3.18 mm
PCB Thickness (Recommended):
.062 in, 1.57 mm
Centerline (Pitch):
.156 in, 3.96 mm
PCB Contact Termination Area Plating Material Thickness:
100 µin, 2.54 µm
CSA Rating:
Certified , LR 7189
Contact Mating Area Plating Material:
Gold , Gold Flash over Palladium Nickel
Product Length:
.78 in, 19.81 mm
Connector Height:
.525 in, 13.33 mm
Approved Standards:
UL E28476
05P MTA156 HDR ASSY STR LF
Search Keywords:
36447595
IN STOCK: 1,900
Can Ship immediately
MOQ for In Stock Qty:
10
MOQ for out of Stock Qty:
500
Factory Lead-Time
17 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$2.508
$25.080
100
$2.002
$200.200
250
$1.824
$456.000
500
$1.766
$883.000
1,000
$1.502
$1,502.000
1,500
$1.487
$2,230.500
2,000 +
$1.449
$2,898.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
