Supplier:
TE Connectivity / AMP Brand
Part No:
3-647123-0
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack
1
Package Type:
Pack
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.96 mm
Number of Contacts:
10
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
7/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 105 °C
10P MTA156 SHRD HDR ASSY SQ SN
Product Highlights:
- MTA-156 Connectors
- Number of Positions = 10
- Mating Type = Header
- Wire-to-Board Application
- 3.96 mm Contact Centerline Spacing
Search Keywords:
36471230
IN STOCK:
1,133
Can Ship immediately
MOQ for In Stock Qty:
5
MOQ for out of Stock Qty:
125
Factory Lead-Time
17 Weeks
Quantity
Unit Price
Ext. Price
5
$4.814
$24.070
25
$4.026
$100.650
50
$3.815
$190.750
125
$3.569
$446.125
250
$3.534
$883.500
375
$3.498
$1,311.750
500
+
$3.235
$1,617.500
Tools/3D Models
3D PDF
Product Drawing - MTA-156 SHROUDED HEADER ASSEMBLY, STRAIGHT .045 SQUARE POST, TIN W/O RETENTION PEG
Datasheet
Product Specification - System, Connector/Header, MTA 156
