3-647166-5 by te connectivity / amp brand
DATA SHEET

3-647166-5

TE Connectivity / AMP Brand

5P MTA100 HDR ASSY,SM,FL,LF .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-647166-5
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Pack
Type:
Wire to Board
Body Orientation:
Straight
Gender:
HDR
Mounting:
Surface Mount
Pitch:
2.54 mm
Number of Contacts:
5
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
5/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 105 °C
The TE Connectivity / AMP Brand part 3-647166-5 is a 5-position MTA100 header assembly, designed for secure and reliable connections in various electronic applications. Featuring a surface mount design with a flanged, latchless mating interface, this header assembly ensures a low profile and easy installation process. With a lead-free finish, this assembly is environmentally friendly and offers excellent conductivity for a wide range of industrial and commercial uses.
Product Highlights:
  • MTA-100 Connectors
  • Number of Positions = 5
  • Mating Type = Header
  • Wire-to-Board Application
  • 2.54 mm Contact Centerline Spacing
Search Keywords:
36471665
IN STOCK: 1,519
Can Ship immediately
On Order:
4,000   can ship 2/12/25
Minimum Order:
10
Factory Lead-Time
14 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$2.481
$24.810
100
$2.073
$207.300
250
$2.041
$510.250
500
$1.668
$834.000
1,000
$1.492
$1,492.000
2,500
$1.477
$3,692.500
5,000
$1.316
$6,580.000
7,500 +
$1.302
$9,765.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
