3-794631-8 by te connectivity / amp brand
DATA SHEET

3-794631-8

TE Connectivity / AMP Brand

Conn Power HDR 8 POS 3mm Solder ST Thru-Hole 8 Terminal 1 Port Tray .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-794631-8
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
234
Package Type:
Tray
Type:
Power3706
Body Orientation:
Straight3686
Mounting:
Through Hole3696
Gender:
HDR3690
Number of Contacts:
8
Termination Method:
Solder3705
Maximum Voltage Rating:
2503694VAC
Maximum Current Rating:
5/Contact A
Operating Temperature:
-40 to 105 °C
The TE Connectivity / AMP Brand part 3-794631-8 is a compact and reliable power connector with 8 positions, designed for easy soldering onto a printed circuit board. This header features a 3mm pitch, straight through-hole mounting style, and includes 8 terminals for secure electrical connections. Packaged in a convenient tray format, this connector is ideal for applications requiring a single port power connection.
Product Highlights:
  • Header Assembly
  • Number of Positions = 8
  • Number of Rows = Dual
  • Vertical Mount Angle
  • Mount Style = Through-Hole
Search Keywords:
37946318
IN STOCK: 296
Can Ship immediately
Minimum Order:
25
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
25
$1.864
$46.600
234
$1.618
$378.612
468
$1.600
$748.800
702
$1.584
$1,111.968
1,170
$1.327
$1,552.590
2,574
$1.277
$3,286.998
5,148
$1.210
$6,229.080
7,722 +
$1.198
$9,250.956
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
