3-794636-4 by TE Connectivity / Amp Brand
DATA SHEET

3-794636-4

TE Connectivity / Amp Brand

Rectangular Connector - Micro MATE-N-LOK Series - 4 Contacts - Header - 3 mm - Surface Mount - 2 Row. .. see full description

  • RoHS Compliant
  • Reel Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
3-794636-4
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Package Type:
Reel
Type:
Wire3594 to Board3594
Body Orientation:
Straight3574
Mounting:
Surface Mount3586
Gender:
HDR3578
Number of Contacts:
4Power
Termination Method:
Solder3593
Maximum Voltage Rating:
2503584VDC,2503584VAC
Maximum Current Rating:
5/Contact A
Operating Temperature:
-40 to 105 °C
The 3-794636-4 is micro MATE-N-LOK series low profile micro MATE-N-LOK Connector has a vertical height of less than 4.7mm - about 45% lower than other members of the product family. These soft-shell connectors include right-angle surface-mount headers and mating cable connectors. The connector features positive latching to prevent unmating. The 94V-0-rated nylon housing is available in black or natural colours. Contacts are phosphor bronze with a choice of tin or gold plating. The connectors are rated up to 5A and 250V. This low-profile connector joins the proven micro MATE-N-LOK line of soft-shell connectors widely used in appliance, industrial machinery and home equipment. The low-profile version was created to meet the specific demands of the lighting industry, but applications are found in other industries, as well.
Product Highlights:
  • Connector
  • With Contacts
  • Housing Gender = Header - Pin
  • Contact Gender = Pin
  • Surface Mount Contact Termination Type
Search Keywords:
37946364
IN STOCK: 18,000
Ships today, if you order in
Minimum Order:
175
Multiple:
175
Factory Lead-Time
22 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
175
$1.120
$196.000
350
$1.090
$381.500
525
$1.060
$556.500
1,050
$1.040
$1,092.000
2,625
$0.990
$2,598.750
5,075
$0.985
$4,998.875
7,525
$0.980
$7,374.500
10,150 +
$0.975
$9,896.250
Please Note: Item may be subject to tariff fee if shipping within the United States
