5-103635-1 by te connectivity / amp brand
DATA SHEET

5-103635-1

TE Connectivity / AMP Brand

Header - Male Pin - 2 Positions - 0.100" (2.54mm) Pitch - Board to Board or Cable - Latch Holder - Solder Termination - Through Hole, Right Angle. .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5-103635-1
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
71
Package Type:
Tube
Type:
Shrouded Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
2
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C
The TE Connectivity / AMP Brand part 5-103635-1 is a high-quality HDRASSY (header assembly), designed with a right angle and single row layout. It features a pitch of 2.54mm [0.100 inches] C/L (center-to-center), and a square post size of 0.64mm [0.025 inches]. Additionally, this assembly includes a PLZN (polarizing) feature and a latching mechanism, providing secure and reliable connections. This AMPMODUMTE 5-103635-1 part serves as a versatile and efficient solution for various electronic applications.
Product Highlights:
  • Header
  • Number of Positions = 2
  • Number of Rows = Single
  • Post Size = 0.64 [.025] mm [in]
  • Terminate To Printed Circuit Board
Search Keywords:
51036351
IN STOCK: 2,989
Ships today, if you order in
Minimum Order:
71
Multiple:
71
Factory Lead-Time
2 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
71
$0.6496
$46.122
284
$0.5352
$151.997
568
$0.5020
$285.136
1,065
$0.4898
$521.637
2,556
$0.4732
$1,209.499
5,041
$0.4661
$2,349.610
7,526
$0.4591
$3,455.187
10,011 +
$0.4522
$4,526.974
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
