DATA SHEET

5-103946-1

TE Connectivity / AMP Brand

8X2 MTE SHRD PIN SR POL .100CL .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5-103946-1
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
72
Package Type:
Tube
Type:
IDC Connector
Body Orientation:
Straight
Gender:
Pin
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
2
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C
The TE Connectivity / AMP Brand part 5-103946-1 is an 8X2 MTE SHRD PIN SR POL .100CL connector. This connector features a compact design with 8 rows and 2 positions, allowing for efficient and reliable connections. It is equipped with shared pins for simplified wiring and a secure polarized design for easy mating. With a .100 centerline spacing, this connector is versatile and well-suited for a variety of applications. Trust in TE Connectivity / AMP Brand's reputation for high-quality and durable products when choosing the 5-103946-1 connector for your connectivity needs.
Product Highlights:
  • Pin Assemblies
  • Wire Termination Type = Crimp, Insulation Displacement Crimp (IDC)
  • Number of Positions = 2
  • Number of Rows = Single
  • Terminate To Wire
Search Keywords:
51039461
IN STOCK: 2,656
Can Ship immediately
Minimum Order:
72
Multiple:
72
Factory Lead-Time
22 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
72
$0.865
$62.280
288
$0.815
$234.720
504
$0.798
$402.192
1,008
$0.790
$796.320
2,520
$0.782
$1,970.640
5,040
$0.774
$3,900.960
7,560
$0.766
$5,790.960
10,008 +
$0.759
$7,596.072
