5227161-3 by te connectivity / amp brand
DATA SHEET

5227161-3

TE Connectivity / AMP Brand

BNC Connector - Jack - Female Socket - 50 Ohms - 4 GHz - 500V - Solder Contact and Shield Termination - Panel Mount, Through Hole, Right Angle. .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5227161-3
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Package Type:
Tube
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Dimension:
14.76 x 34.93 x 15.88 mm
The 5227161-3 from TE Connectivity / AMP Brand is a white through-hole BNC Right Angle Jack for use with printed circuit board (PCB). It has nickel-plated zinc body with gold-plated phosphor bronze centre contact and a polymethylpentene insulator.
Product Highlights:
  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • Not Stacked
Search Keywords:
52271613
IN STOCK: 1,555
Can Ship immediately
Minimum Order:
35
Multiple:
35
Factory Lead-Time
2 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
35
$2.408
$84.280
70
$2.124
$148.680
280
$1.911
$535.080
525
$1.882
$988.050
1,015
$1.863
$1,890.945
2,520
$1.845
$4,649.400
5,005
$1.826
$9,139.130
7,525 +
$1.808
$13,605.200
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
