52927-1
TE Connectivity / AMP BrandFork / Spade Tongue Terminal - PIDG Series - 22 AWG - 16 AWG - 1.42 mm² - M2.5 - #4. .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
52927-1
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack
5000
Package Type:
Box
Type:
Spring Spade Terminal
Gender:
N/A
Tab Size:
N/A
Stud Size:
2.84 mm
Wire Size:
16-22 AWG
Color:
Red
Operating Temperature:
N/A
Create a connection between two terminal blocks by using this spring spade terminal 52927-1 wire terminal from TE Connectivity. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. Its wire is 16-22 AWG. This product is 20.29 mm long and 5.15 mm.
Product Highlights:
- Terminal Shape = Spring Spade, Short
- Receptacle Style = Straight
- Body Style = PIDG
- Barrel Type = Closed Barrel
- Wire/Cable Type = Regular Wire
Search Keywords:
529271
Different packaging options available. See Alternatives
IN STOCK:
7,452
Can Ship immediately
Minimum Order:
50
Factory Lead-Time
30 Weeks
Quantity
Unit Price
Ext. Price
50
$0.4473
$22.365
500
$0.2859
$142.950
1,000
$0.2800
$280.000
2,500
$0.2759
$689.750
5,000
$0.2731
$1,365.500
10,000
$0.2644
$2,644.000
15,000
$0.2615
$3,922.500
25,000
+
$0.2585
$6,462.500
3D PDF
Product Guides
Product Drawing - WIRE TERMINAL, PIDG, SPRING SPADE WIRE SIZE: 22-16
Datasheet
Agency Approval Document - WIRE CONN, TERMINALS, BUTT AND PARALLEL CONNECTORS-PLASTI-GRIP, SOLISTRAND, STD B, DIAMOND GRIP, PIDG AND AMPOWER REPORT
Instruction Sheet - AMP* PIDG* (VINYL) & PLASTI-GRIP* SHORT SPRING SPADE TERMINALS FOR BAR
