5499141-3 by te connectivity / amp brand
DATA SHEET

5499141-3

TE Connectivity / AMP Brand

A/L UNIV HDR 16P RA LG LAT .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5499141-3
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
56
Package Type:
Tray
Type:
Ejector Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
16
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C
A/L UNIV HDR 16P RA LG LAT
Product Highlights:
  • Connector Type = Universal Ejection Pin Headers
  • Standard Profile
  • Number of Positions = 16
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Right Angle
Search Keywords:
54991413
IN STOCK: 757
Can Ship immediately
Minimum Order:
56
Multiple:
56
Factory Lead-Time
7 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
56
$2.338
$130.928
112
$2.290
$256.480
280
$2.257
$631.960
504
$2.234
$1,125.936
1,008
$2.212
$2,229.696
2,520
$2.190
$5,518.800
5,040
$2.168
$10,926.720
7,504 +
$2.146
$16,103.584
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
