5499922-1 by te connectivity / amp brand
DATA SHEET

5499922-1

TE Connectivity / AMP Brand

Wire-To-Board Connector - Straight - 2.54 mm - 10 Contacts - Header - AMP-LATCH Series - Through Hole. .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5499922-1
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
54
Package Type:
Tray
Type:
Ejector Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C
The 5499922-1 is a 10-position 2-row vertical shrouded Wire-to-Board Universal Ejection-style Pin Header with gold-plated brass, phosphor bronze pin contacts and black glass filled nylon/polyester 4-sided housing. The plug supports through-hole termination method PC board and latch mating connector lock type. It is applicable to printed circuit board.
Product Highlights:
  • Connector Type = Universal Ejection Pin Headers
  • Standard Profile
  • Number of Positions = 10
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Vertical
Search Keywords:
54999221
IN STOCK: 6,727
Ships today, if you order in
Manufacturer Stock:
3,834   can ship 12/6/24
Minimum Order:
54
Multiple:
54
Factory Lead-Time
2 Weeks can ship 12/5/24
Enter Quantity
Quantity
Unit Price
Ext. Price
54
$1.38
$74.520
270
$1.32
$356.400
540
$1.27
$685.800
1,026
$1.24
$1,272.240
2,538
$1.17
$2,969.460
5,022
$1.15
$5,775.300
7,506
$1.14
$8,556.840
10,044 +
$1.12
$11,249.280
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
