5747871-8 by te connectivity / amp brand
DATA SHEET

5747871-8

TE Connectivity / AMP Brand

9 Position D-Sub Plug, Male Pins Connector .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5747871-8
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
The 5747871-8 is a 9-position 2-row standard D-sub Plug with gold-plated brass contacts, 4-40 threaded inserts and size-1 tin-plated steel shell. The HD-20 straight posted connector in front metal-shell. The HD-20 connector has action pin contacts. UL94V-0 Rated black thermoplastic housing Number of Positions: 9 Position Contact Gender: Pin (Male) Termination Style: Through Hole Number of Rows: 2 Row Shell Size: 1 (E) Contact Plating: Gold Packaging: Tube Gender: Male Type: Plug Shell Material: Steel Applications Industrial
Product Highlights:
  • Number of Positions = 9
  • Plug
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • With Mating Connector Lock
Search Keywords:
57478718
IN STOCK: 898
Ships today, if you order in
Minimum Order:
17
Multiple:
17
Factory Lead-Time
6 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
17
$5.15
$87.550
51
$4.98
$253.980
102
$4.76
$485.520
255
$4.56
$1,162.800
510
$4.37
$2,228.700
1,003
$4.25
$4,262.750
2,516
$3.62
$9,107.920
5,015 +
$3.27
$16,399.050
