5-747909-2 by te connectivity / amp brand
DATA SHEET

5-747909-2

TE Connectivity / AMP Brand

15 Position D-Sub Receptacle, Female Sockets Connector .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5-747909-2
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
SKT
Termination Method:
Solder Cup
Shell Size:
2
Number of Contacts:
15
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
The 5-747909-2 is a 15-way Solder D-sub Receptacle with tin-plated steel shell, gold-plated phosphor bronze contacts and thermoplastic insert. This HD20 series solder cup connector comes with mounting holes and tin-copper over nickel plated solder tail. It accepts 20AWG wire and intermates with other sub miniature D connectors. This connector features crimped shield termination for low impedance, anti-solder wicking contact design, shields offer full EMI shielding and ESD insulation. Shield crimp provides strain relief Easy application without special application tools UL94V-0 Flammability rating Applications Industrial
Product Highlights:
  • Connector
  • Product Series = HD-20 (Solder Cup)
  • Number of Positions = 15
  • Receptacle
  • With Contacts
Search Keywords:
57479092
IN STOCK: 519
Can Ship immediately
On Order:
6,000   can ship 1/15/25
Minimum Order:
5
Factory Lead-Time
10 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$5.38
$26.900
25
$3.79
$94.750
100
$3.63
$363.000
250
$3.56
$890.000
500
$3.50
$1,750.000
1,000
$3.43
$3,430.000
2,500
$3.38
$8,450.000
5,000 +
$3.33
$16,650.000
