6469025-1 by te connectivity / amp brand
DATA SHEET

6469025-1

TE Connectivity / AMP Brand

Connector - Z-PACK Series - 40 Contacts - 2.5 mm - Header - Press Fit - 4 Rows. .. see full description

  • RoHS Compliant
  • Tube Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
6469025-1
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:
20
Package Type:
Tube
Type:
High Speed
Gender:
HDR
Body Orientation:
Straight
Mounting:
Through Hole
Pitch:
2.5 mm
Number of Contacts:
40Signal/20Ground
Termination Method:
PRESS FIT
Operating Temperature:
-65 to 105 °C
When you have numerous wires connected in parallel, then use this high speed 6469025-1 backplane connector from TE Connectivity to make sure all the data flows through. This HDR connector's 40signal / 20ground contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. Its pitch is 2.5 mm. It has a straight body orientation. It has a maximum voltage rating of 250 VAC. This is a 4-row connector. This device has a maximum current rating of 7 A/contact. In order to ensure parts aren't damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the press fit termination method. This backplane connector has an operating temperature of -65 to 105 °C. This product is 24.95 mm long, 13.4 mm tall and 15.43 mm deep. 6469025-1 is housed in polyester.
Product Highlights:
  • Header
  • Connector Type = 10 Column
  • Interface Type = HM-Zd
  • Contact Type = ACTION PIN Post
  • Feedthrough Post Length = 2.50 mm
Search Keywords:
64690251
IN STOCK: 35,976
Can Ship immediately
Minimum Order:
20
Multiple:
20
Factory Lead-Time
3 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
20
$6.93
$138.600
40
$6.74
$269.600
60
$6.61
$396.600
100
$6.44
$644.000
260
$6.31
$1,640.600
500
$6.20
$3,100.000
1,000 +
$6.07
$6,070.000
Please Note: Item may be subject to tariff fee if shipping within the United States
