650473-5 by te connectivity / amp brand
DATA SHEET

650473-5

TE Connectivity / AMP Brand

Edge Connector - Plug - Male Pins - 96 Positions - 3 Rows - 0.100" (2.54mm) Pitch - Style C - Solder Termination - Through Hole, Right Angle. .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
650473-5
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
Pack
Type:
DIN 41612
Gender:
Pin
Body Orientation:
Right Angle
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
96
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C
The 650473-5 is edge connector with operating temperature range from -55 to 105 °C ( -67 to 221 °F ).
Product Highlights:
  • Type C Connectors
  • Plug
  • Number of Positions = 96
  • Rows Loaded = A, B, C
  • Terminate To Printed Circuit Board
Search Keywords:
6504735
  Possible Replacement options available.  See Alternatives
IN STOCK: 3,549
Can Ship immediately
On Order:
1,500   can ship 1/20/25
Minimum Order:
30
Multiple:
30
Factory Lead-Time
9 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
30
$3.38
$101.400
60
$3.32
$199.200
120
$3.27
$392.400
270
$3.17
$855.900
510
$3.08
$1,570.800
1,020
$3.04
$3,100.800
2,520
$2.99
$7,534.800
5,010 +
$2.95
$14,779.500
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
