6-534206-4 by te connectivity / amp brand
DATA SHEET

6-534206-4

TE Connectivity / AMP Brand

28 MODII VRT DR CE 100/115 .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
6-534206-4
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
16
Package Type:
Tube
Type:
Socket Strip
Body Orientation:
Straight
Gender:
SKT
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
28
Maximum Voltage Rating:
N/A
Maximum Current Rating:
2/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C
The TE Connectivity / AMP Brand part 6-534206-4 is a receptacle assembly for the MOD II system. It features a double row design with dual entry points, allowing for easy insertion and removal of wires. With a .100x.100CL pitch, this vertical mount assembly is perfect for applications where space is limited. Designed with the AMPMODU standard, this assembly ensures reliable and secure connections.
Product Highlights:
  • Receptacle
  • Mod II
  • Number of Positions = 28
  • Number of Rows = Dual
  • Standard Profile
Search Keywords:
65342064
  Possible Replacement options available.  See Alternatives
IN STOCK: 4,304
Can Ship immediately
Minimum Order:
16
Multiple:
16
Factory Lead-Time
16 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
16
$4.87
$77.920
64
$4.66
$298.240
112
$4.25
$476.000
256
$4.18
$1,070.080
512
$3.90
$1,996.800
1,008
$3.64
$3,669.120
2,512
$3.58
$8,992.960
5,008 +
$3.53
$17,678.240
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
