66602-2
TE Connectivity / AMP BrandPin Contact Gold Crimp 14-18 AWG Stamped .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
66602-2
RoHS:
Yes
HTS:
8536904000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:
1000
Package Type:
Carton
Contact Type:
Signal
Gender:
Pin
Contact Size:
16
Wire Size:
14-18 AWG
Contact Material:
Brass
Contact Plating:
Gold
Maximum Current Rating:
N/A
Termination Method:
Crimp
The 66602-2 is a pin Signal Contact made of brass with gold plated finish. It accepts 18 to 14AWG wire size. The Type III+ series crimp contact is suitable for CPC and M series connectors.
13A Test current Contact Gender: Pin (Male)
Current Rating: 13 A
Termination Style: Crimp
Contact Plating: Tin
Series: Multimate Type III+
Packaging: Bulk
Product: Contacts
Applications
Industrial, Commercial
Product Highlights:
- Pin
- Gold (30) over Nickel (50) Contact Mating Area Plating Material
- Wire Range = 0.80-2.00² [18-14] mm [AWG]
- Insulation Diameter = 2.79 - 3.81 mm
- Brass Contact Base Material
Search Keywords:
666022
Different packaging options available. See Alternatives
IN STOCK:
10,697
Ships today, if you order in
On Order:
8,000
can ship 11/11/24
Minimum Order:
25
Factory Lead-Time
12 Weeks
Quantity
Unit Price
Ext. Price
25
$1.011
$25.275
250
$0.733
$183.250
500
$0.718
$359.000
1,000
$0.707
$707.000
3,000
$0.683
$2,049.000
5,000
$0.676
$3,380.000
8,000
$0.669
$5,352.000
10,000
+
$0.663
$6,630.000
