770849-5 by te connectivity / amp brand
DATA SHEET

770849-5

TE Connectivity / AMP Brand

05P SL156 HSG W/LCK RMP & HSG .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
770849-5
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Bag
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
5
Maximum Voltage Rating:
205 VAC
Maximum Current Rating:
10/Contact A
Operating Temperature:
-55 to 105 °C
TE Connectivity / AMP Brand part 770849-5 is a high-quality housing connector that is a perfect fit for various applications. This connector features 5 pins and a pitch rating of 0.156 inches. It comes with a locking mechanism, ensuring a secure and reliable connection. The housing is designed to be resistant to wear and tear, ensuring longevity and durability. The 770849-5 connector is an essential component for any electrical or electronic system that requires a safe and efficient connection.
Product Highlights:
  • SL-156 Housings
  • Number of Positions = 5
  • Mating Type = Receptacle
  • Wire-to-Board Application
  • 3.96 mm Contact Centerline Spacing
Search Keywords:
7708495
IN STOCK: 110,657
Can Ship immediately
Minimum Order:
500
Multiple:
500
Factory Lead-Time
13 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
500
$0.1633
$81.650
2,500
$0.1478
$369.500
5,000
$0.1456
$728.000
7,500
$0.1434
$1,075.500
10,000
$0.1403
$1,403.000
25,000
$0.1352
$3,380.000
50,000
$0.1191
$5,955.000
100,000 +
$0.1173
$11,730.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
