8-1393211-4 by te connectivity / amp brand
DATA SHEET

8-1393211-4

TE Connectivity / AMP Brand

General Purpose Relay DPDT (2 Form C) 120VAC Coil Chassis Mount .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
8-1393211-4
Alias/AKA:
T92S11A22-120
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
110,120 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT
Maximum Current Rating:
40(NO)/3(NC) A
Mounting:
Flange Mount
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-55 to 65 °C
The T92S11A22-120 is a 2-pole general purpose High-power Relay with panel mount via flanged cover, 950Ω coil resistance, 120VAC coil voltage and silver cadmium oxide contacts. DPDT contact configuration 500mA at 12V minimum contact switching load 6000V initial surge withstand voltage between contacts and coil Monostable AC coil magnetic system Class F UL coil insulation Applications HVAC, Commercial, Industrial
Product Highlights:
  • T92 Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 30 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 110 VAC, 120 VAC
Search Keywords:
813932114
IN STOCK: 2,381
Ships today, if you order in
On Order:
1,200   can ship 11/25/24
3,960   can ship 1/15/25
Factory Lead-Time
19 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$29.38
$29.380
10
$18.50
$185.000
30
$17.60
$528.000
60
$16.96
$1,017.600
120
$16.42
$1,970.400
270
$16.16
$4,363.200
510 +
$15.91
$8,114.100
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
