9-146280-0 by te connectivity / amp brand
DATA SHEET

9-146280-0

TE Connectivity / AMP Brand

Board-To-Board Connector - 2.54 mm - 40 Contacts - Header - AMPMODU Mod II Series - Through Hole - 1 Rows. .. see full description

RoHS Compliant
Carton Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
9-146280-0
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Carton
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
40
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C
The 9-146280-0 is AMPMODU Mod II breakaway PCB headers can be broken into the size required. All the solder posts can be installed at one time saving time and labour costs. These AMPMODU Mod II PCB pin headers are suitable for use in a wide range of applications. Applications include automotive controls, industrial and test equipment, computers, telecommunications, medical instruments, storage equipment and appliances.
Product Highlights:
  • Connector
  • Connector Type = Header - Pin
  • Header Type = Breakaway
  • 40 Positions
  • Mating Post Length = 5.84 mm
Search Keywords:
91462800
IN STOCK: 6,686
Ships today, if you order in
MOQ for In Stock Qty:
5
MOQ for out of Stock Qty:
500
Factory Lead-Time
11 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$7.67
$38.350
100
$5.02
$502.000
250
$4.95
$1,237.500
500
$4.87
$2,435.000
1,000
$2.71
$2,710.000
1,500
$2.67
$4,005.000
2,000 +
$2.63
$5,260.000
Suppliers Standard Package
Older Equivalent
9-146292-0
9-146292-0
VIEW PRODUCT
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
Product Guides
PDF Datasheet
