PD10AB57 by te connectivity / kilovac brand
DATA SHEET

PD10AB57

TE Connectivity / Kilovac Brand

Electromechanical Relay 24VDC 290Ohm 20A SPST-NO (78.7x22.3x37.6)mm Panel Power Relay .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Kilovac Brand
Part No:
PD10AB57
Alias/AKA:
1618256-9
RoHS:
Yes
HTS:
8536490075
COO:
IN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
20 A
Mounting:
Panel Mount
Termination Style:
Stud Terminal
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
The TE Connectivity / Kilovac Brand PD10AB57 is a high-quality electromechanical relay designed for various power applications. This powerful SPST-NO (Single Pole Single Throw - Normally Open) relay has a coil voltage of 24VDC and a coil resistance of 290 Ohms. With a maximum switching current of 20A, it is capable of handling substantial power loads.Featuring a compact design with dimensions of 78.7x22.3x37.6mm, this panel power relay can fit seamlessly into various electrical panels and systems. Its reliable construction ensures long-lasting performance and efficient operation. The TE Connectivity / Kilovac Brand PD10AB57 is suitable for use in a wide range of industrial and commercial applications, including power distribution, automotive systems, HVAC, and more. With its high current capacity and robust design, this relay provides a reliable solution for demanding power switching requirements.
Product Highlights:
  • Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
  • Power Switching = Make Only, Yes, No
  • Contact Current Rating = 0 - 10 Amps.
  • Not RF Rated
  • Coil Voltage = 24 VDC
Search Keywords:
PD10AB57
IN STOCK: 18
Can Ship immediately
On Order:
50   can ship 5/7/25
Factory Lead-Time
52 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$468.91
$468.910
3
$461.87
$1,385.610
5
$454.94
$2,274.700
10 +
$447.75
$4,477.500
