IM06TS by te connectivity / p-b brand
DATA SHEET

IM06TS

TE Connectivity / P&B Brand

Signal Relay 12VDC 2A DPDT(10x6x5.65)mm THT .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
IM06TS
Alias/AKA:
2-1462037-7
RoHS:
Yes
HTS:
8536410030
COO:
PT
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Dimension:
10 x 6 x 5.7 mm
Termination Style:
PC Pin
Coil Current:
11.67 mA
Contact Form:
2 Form C
TE Connectivity/P&B Brand part IM06TS is a signal relay that operates at 12VDC and can handle a current of up to 2A. It features a double-pole double-throw (DPDT) configuration, making it suitable for various switching applications. The relay has compact dimensions, measuring 10mm x 6mm x 5.65mm, and is designed for through-hole mounting. With its reliable performance and small footprint, the IM06TS is an ideal choice for electronic projects demanding efficient signal relay switching.
Product Highlights:
  • IM Relay Series
  • DC Actuating System
  • Input Voltage = 12 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 2 Amps.
Search Keywords:
IM06TS
  Possible Replacement options available.  See Alternatives
IN STOCK: 30,294
Ships today, if you order in
On Order:
4,365   can ship 1/1/25
Minimum Order:
5
Factory Lead-Time
39 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$3.48
$17.400
50
$2.45
$122.500
100
$2.40
$240.000
250
$2.27
$567.500
500
$2.00
$1,000.000
1,000
$1.84
$1,840.000
3,000
$1.82
$5,460.000
5,000 +
$1.79
$8,950.000
Suppliers Standard Package
Older Equivalent
OUAZ-SH-112D,405
OUAZ-SH-112D,405
VIEW PRODUCT
