KRPA-11AG-120 by te connectivity / p-b brand
DATA SHEET

KRPA-11AG-120

TE Connectivity / P&B Brand

Electromechanical Relay 120VAC 2.25KOhm 10A DPDT(35.71x35.71x50.8)mm Socket General Purpose Relay .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / P&B Brand
Part No:
KRPA-11AG-120
Alias/AKA:
2-1393104-5
RoHS:
Yes
HTS:
8536490075
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Tray
Relay Construction:
Non-Latching
AC Coil Voltage:
120 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT
Maximum Current Rating:
10 A
Mounting:
Socket
Termination Style:
8-Pin Circular Plug
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 55 °C
Coil Resistance:
2.25 KOhm
The TE Connectivity / P&B Brand part KRPA-11AG-120 is a versatile and reliable electromechanical relay designed for general purpose applications. It operates on 120VAC and features a double-pole, double-throw configuration, allowing it to be used in various switching and control tasks. With a compact size of 35.71x35.71x50.8mm, this relay can easily fit into tight spaces. It offers a coil resistance of 2.25KOhm and is capable of handling up to 10A of current. This relay is compatible with a socket for easy installation and maintenance. Trust TE Connectivity / P&B Brand's KRPA-11AG-120 to deliver exceptional performance and durability in a wide range of applications.
Product Highlights:
  • KRPA Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 120 VAC
Search Keywords:
KRPA11AG120
IN STOCK: 847
Ships today, if you order in
On Order:
900   can ship 1/1/25
1,050   can ship 1/29/25
Factory Lead-Time
21 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$31.29
$31.290
5
$23.16
$115.800
25
$22.08
$552.000
50
$19.86
$993.000
100
$19.57
$1,957.000
250
$19.27
$4,817.500
500 +
$18.98
$9,490.000
